Panel Saw Precision

Panel Saw Precision

Motor power 3kw(3 PH ),2.2kw(1PH)
Dimension of sliding table 2800*375mm
Gross cut capacity 2800mm
Width of cut between saw blade and rip fence 1250mm
Saw blade diameter 300mm(250-300)
Height of cut (diameter:300mm) 85mm
Height of cut with saw blade 300mm at 45 angle 55mm
Speed ??of main saw spindle 4000/6000rpm
Main spindle diameter 30mm
Tilt saw blade 45 degree
Main motor 5.5kw
Scoring saw blade diameter 120mm
Speed ??of scoring saw blade 8000r/min
Scoring spindle diameter 20mm
Scoring motor 0.75kw
